IT Catalog | SKYNXT Technologies

Catalog highlights

A smarter way to rack, monitor, cool, and protect critical IT assets.

The catalog emphasizes robust build quality, scalable formats, compact efficiency, and comprehensive threat protection.

Edge Micro Data Centre

A curated micro data centre approach designed for compact, reliable, and monitored IT infrastructure.

Smart Rack Protection

Threat protection against heat, environmental hazards, fire, theft, power interruptions, and unauthorized access.

Remote Monitoring

RMU/DCIM software supports real-time monitoring, event logs, alarms, and email/SMS alert management.

Built to Scale

Flexible single or dual rack formats with 28U of practical usable space and scalable customization.

Technical features

Core systems inside the edge micro data centre approach.

Power distribution, cooling, UPS, environmental sensing, surveillance, access control, and fire detection work together.

Power Distribution Unit

32A input, two x 16A with MCB and LCD display, 3m industrial power cord, 24 IEC outlets, and basic or IP-based PDU options.

Closed Loop Rack Precision AC

Rack-mount AC from 3.5–10 kW using environment-friendly refrigerant, bottom-mounted split-type cooling, and uniform bottom-to-top airflow.

Uninterruptible Power

Rack-mount UPS from 3–11 kVA with LED display, typical 15-minute backup, 0.9 power factor, and optional redundancy.

Environmental Sensing

Temperature, humidity, smoke detection, airflow, water leak detection, vandalism sensor, and rodent sensor.

Surveillance & Access Control

IP-based dome/bullet camera, NVR option, electronic locking with RFID/biometric/swipe card options, and access logs.

Fire Detection & Control

Automatic fire detection, cylinder-type unit, Novec 1230 suppressant, VESDA option, and backup power for fire suppression.

Specifications Explorer

Detailed technical specs by category

Click on any tab below to review the certified specifications of our micro data centre infrastructure.

Enclosure & Frame Specifications
Parameter	Certified Value
Cabinet Rating	42U IT Enclosure, rated to IP54 & EIA-310 standards
Load Capacity	Up to 1400 kg load-bearing capacity
Frame Build	5-fold welded CRCA Steel frame with corrosion resistance
Access Configuration	LH & RH swappable doors, screw-mount side panels

Power & UPS Specifications
Parameter	Certified Value
Power Distribution	32A input, 2x 16A with MCB, LCD display, 24 outlets (20x C13, 4x C19)
UPS Rating	3kVA to 11kVA load rating with 0.9 power factor
Battery Backup	15 minutes typical backup, rack-mountable VRLA batteries

Cooling System Specifications
Parameter	Certified Value
AC Capacity	Rack-mount precision AC, 3.5kW to 10kW capacity
Airflow Direction	Uniform bottom-to-top air throw for sensible heat removal
Refrigerant	Environment-friendly ozone-safe refrigerant

Monitoring & Safety Specifications
Parameter	Certified Value
Software Management	Integrated web-based RMU / DCIM for real-time tracking
Fire Suppression	Novec 1230 suppressant cylinder (VESDA option available)
Sensors Installed	Temperature, humidity, smoke, water leak, vandalism, rodent sensors

The Fearsome Five

Designed around the five threats that interrupt data infrastructure

The catalog identifies heat, fire, theft, environment, and power as the critical risks the smart rack addresses. Click each threat to review its specific mitigation tech.

H

Heat

➔

Insulation and precision cooling help manage temperature and prevent equipment overheating.

Mitigation technology: Mitigated by built-in 3.5 kW to 10 kW Precision Air Conditioner meeting ASHRAE standards, providing uniform bottom-to-top throw cooling.

F

Fire

➔

Automatic fire detection with Novec 1230 suppressant and VESDA option for early warning.

Mitigation technology: Mitigated by automatic fire suppression unit using eco-friendly Novec 1230 agent with optional VESDA (Very Early Warning Aspirating Smoke Detection).

T

Theft & Vandalism

➔

Electronic locking with RFID, biometric, and swipe card options plus access logs.

Mitigation technology: Mitigated by RFID, Biometric, or Swipe card access control, automatic rear door opening system, NVR dome cameras, and 1 TB local storage.

E

Environmental hazards

➔

Sensors track humidity, airflow, water leak, smoke, and dust risk in real time.

Mitigation technology: Mitigated by integrated sensing for temperature, humidity, smoke, airflow, water leakage, and optional rodent repellent systems.

P

Power glitches

➔

UPS, PDU monitoring, and email/SMS alerts reduce interruption risk and downtime.

Mitigation technology: Mitigated by rack-mounted 3kVA to 11kVA UPS with 15-minute VRLA battery backup and socket-level IP-based PDU monitoring.

Prestigious clients

Trusted by leading organizations across telecom, IT, and infrastructure.

The IT catalog lists clients who rely on SKYNXT for edge data centre and smart rack deployments.

[object Object] Enterprise Partner

Talk to SKYNXT

Ready to plan your next project?

Reach out for technical consultation, site survey planning, product selection, solar sizing, or edge micro data centre requirements.
